Description
BUILT FOR RELIABILITY, ENGINEERED FOR CONVENIENCE.
Enjoy fast, reliable and convenient printing with Epson’s LQ-2090II dot matrix printer. Based on Epson’s experience in delivering industry-standard solutions, this printer helps to run and grow your business while you stay in control of your operations. Experience unparalleled durability and minimum downtime with a mean time between failure (MTBF) rating of 25,000 POH (power on hours) and printhead life of up to 400 million characters. A high character yield of up to 8 million means low running costs and more affordable prints.
- 24-pin wide carriage
- Speed: Up to 487 cps (10cpi)
- Prints up to 7-part forms
- 25,000 power on hours MTBF
- USB 2.0, Bi-directional Parallel Supported
Increate Productivity
Enjoy maximum productivity with fast print speeds of up to 487 cps (10 cpi) and 128 kb memory buffer.
Multiple Copy Capability
High copy capability of up to 7 layers (1 original + 6 copies)^ means sharp, clear documents right through the last copy.
Specifications
Printing Technology:
Print Method:Impact dot matrix
Print Speed:
Ultra High Speed Draft:10cpi: 550cps
Reliability:
Printhead Life:400 million strokes / wire
Print Characteristics:
Character Sets:1 Italic and 12 graphical character tables: Italic table, PC437 (US, Standard Europe), PC850 (Multilingual), PC860 (Portuguese)*1
PC861 (Icelandic), PC865 (Nordic), PC863 (Canadian-French), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858, ISO 8859-15
Paper Path:
Manual Insertion:Front or rear in-top out
Paper Media:
Cut Sheet (Single Sheet):
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.065 - 0.14 mm | (0.0025 - 0.0055”)
Entry: Rear
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.065 - 0.14 mm | (0.0025 - 0.0055”)
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.12 - 0.46 mm | (0.0047 - 0.018”)
Copies: 1 Original + 5 copies
Length: 101.6 - 558.8 mm | (4.0 - 22.0”)
Width: 101.6 - 406.4 mm | (4.0 - 16.0”)
Thickness: 0.065 - 0.49 mm | (0.0025 - 0.019”)
Copies: 1 Original + 6 copies
Length: 92mm | (3.6”)
Width: 165mm | (6.5”)
Thickness: 0.16 - 0.52 mm | (0.0063 - 0.0205”)
Length: 105mm | (4.1”)
Width: 241mm | (9.5”)
Thickness: 0.16 - 0.52 mm | (0.0063 - 0.0205”)
Length: 101.6 - 558.8 mm | (4.0 - 22.0”)
Width: 101.6 - 406.4 mm | (4.0 - 16.0”)
Thickness: 0.16 - 0.19 mm | (0.0063 - 0.0075”)
Length: 100 - 148 mm | (3.9 - 5.8”)
Width: 100 - 148 mm | (3.9 - 5.8”)
Thickness: 0.22mm | (0.0087”)
Width: 216mm | (8.5”)
Thickness: 0.07 - 0.09 mm | (0.0028 - 0.035”)
General:
Input Data Buffer:128 KB
Supported OS and Applications:
Printer Driver:Microsoft Windows XP / Vista / 7 / 8 / 10
Epson Setting Utility: Microsoft Windows XP / Vista / 7 / 8 / 10
